Color Retention (ΔE)
ΔE ≤ 2
UV + heating + spraying test (GB/T 16422.2 reference)
9 mil Thickness
hydrophobic
coating
Hydrophobic coating technology that repels water and contaminants for easier maintenance.
9 mil
Thickness
Paint protection film thickness for enhanced impact resistance and long-term durability.
Reinforced protection
Reinforced protection against rock chips, road debris, and daily wear.
EvoFlex Pro™
EvoFlex Pro™ features a reinforced structure for improved impact resistance and deeper gloss, helping maintain a clean, protected finish over time.Its clear, hydrophobic, self-healing film protects against rock chips, scratches, and environmental exposure, backed by a 10-year durability standard.
OPTICAL-GRADE CLARITY
Premium aliphatic TPU provides exceptional transparency, allowing both original paint and color-infused layers to show through with no orange peel or haze.
SELF-HEALING TOPCOAT
Our advanced topcoat formulation self-heals light scratches and swirl marks when exposed to heat, maintaining a smooth, glossy surface.
IMPACT & CHIP DEFENSE
Durable 8 mil TPU construction absorbs road debris, gravel strikes, door dings, and environmental contaminants to help keep the paint protected.
UV & YELLOWING RESISTANCE
CoreGuard’s proprietary UV-stabilizing system minimizes discoloration and preserves long-term color accuracy and clarity.
INSTALLER-FOCUSED DESIGN
Low-tack, repositionable adhesive, enhanced stretchability, and micro-air-release channels ensure faster, cleaner, and bubble-free installations.
GET A QUOTE
Technical Specifications
Property
Typical Values (Avg)
Testing Conditions
Gloss Level (60°)
≥ 94°
Measured before / after surface abrasion & weathering
Elongation at Break
≥280（%）
Standard tensile test
Peel Strength (20 min）
≥ 15 N / 25mm（24h adhesion）
180° peel on automotive paint
Peel Strength (24 hrs)
≥ 15 N / 25mm（24h adhesion）
180° peel after 24-hour set
Self-Healing
Heat self-healing
Copper wire brush (≤0.1 mm) ×10, then heated with heat gun or 100°C boiling water
Hydrophobic Performance
Hydrophobic surface
Water spray / visual inspection
Sample Appearance
Uniform surface, no defects before test
Visual inspection
Film Thickness
9 mil
Measured sample
Sample Appearance
Uniform surface, no defects before test
Visual inspection
FAQs
What is the difference between EvoFlex Pro and EvoFlex 8?
The main difference between EvoFlex 8 and EvoFlex Pro is the level of protection and film thickness.
EvoFlex Pro uses a thicker 9 mil paint protection film designed for enhanced impact resistance and maximum durability. EvoFlex 8 features a more flexible 8 mil film that provides balanced protection and easier installation on complex vehicle surfaces.
Both films are engineered with TPU construction and self-healing technology, allowing installers and vehicle owners to choose the protection level that best fits their driving conditions and protection needs.
Can EvoFlex Pro be installed on a full vehicle?
Yes. EvoFlex Pro can be installed on individual panels or across the entire vehicle depending on the level of protection desired.
Will EvoFlex Pro affect the appearance of my paint?
No. EvoFlex Pro is designed to maintain high optical clarity while enhancing the gloss and depth of the original paint finish.
Is thicker PPF better for protection?
Thicker paint protection films generally provide greater impact absorption and chip resistance. EvoFlex Pro’s 9 mil TPU construction is designed to offer enhanced durability while still maintaining installation flexibility.
